Manufacturing Infrastructure & In-House Capabilities

World-Class Valve Manufacturing Facilities

Spanning over 30,000 sq. ft. in Ahmedabad, Gujarat — featuring our in-house induction melting foundry, precision shell core casting lines, CNC machining, and calibrated API 598 hydro testing rigs.

30,000+ Sq. Ft. Integrated Facility Captive Induction Foundry & Sand Plant 100% In-House Hydro & Air Testing

Headquarters & Engineering

Corporate Office & Design Center

Modern corporate offices housing executive administration, 3D CAD valve modeling suites, FEA computational fluid dynamics, quality audit desks, and domestic & international client support.

3D SolidWorks / AutoCAD Modeling Finite Element Stress Analysis (FEA) Client Technical Conference Suites ERP Order Lifecycle Tracking

Executive Boardroom & Conference

Administrative Operations Wing

Engineering & CAD Design Desk

Corporate Client Support Bay

Main Headquarters Reception & Overview

Shell Core & Molding

Precision Shell Mold & Investment Casting

Specialized shell core and investment casting bays dedicated to producing zero-defect valve body castings, bonnet covers, discs, and yokes with tight dimensional accuracy and flawless grain structure.

Automated Shell Core Shooting Micro-Tolerance Wax Patterns Radiographic Soundness Inspection Smooth Surface Low-Roughness Castings

High Integrity Valve Shell Castings

Precision Core Shell Assembly

Shell Pattern Mold Staging

Core Shooting & Cooling Line

Raw Casting Dimensional Verification

Induction Melting & Pouring

High-Capacity Induction Melting Foundry

Our captive foundry equipped with medium-frequency induction furnaces, controlled ladle preheating, argon de-gassing, and automated sand reclamation for carbon steel, stainless steel, and alloy melts.

Medium-Freq Induction Melting Optical Emission Spectrometer Lab Argon Purging & De-Slagging Alloy 20 / Duplex / Monel Pouring

Ladle Pouring into Heavy Flask Molds

Induction Furnace Tapping & Slagging

High Temperature Liquid Metal Heat Control

Foundry Floor Mold Preparation Line

Heavy Valve Body Cast Flask Shakeout

Hydro Testing & Global Export

Quality Testing, Packaging & Dispatch Bay

High-volume final valve assembly bay featuring certified API 598 hydrostatic shell & seat test rigs, automated shot blasting, corrosion-resistant epoxy painting, and ISPM-15 export wooden crating.

10,000 PSI Calibrated Hydro Benches Pneumatic Bubble-Tight Seat Testing High-Mil Epoxy Paint Booth ISPM-15 Fumigated Export Crates

Large Bore Wafer Butterfly Valves Staging

Batch Production of Stainless Steel Ball Valves

ALLIED Branded Cast Steel Gate Valves

Protective Coating & Final Quality Inspection

Shop Floor Valve Assembly in Progress

Flanged Valves Inspection & Tagging

Protective End Flange Cap Staging

Export Quality Wooden Box Packing

Container Loading & Global Dispatch

Quality Control Ecosystem

Completely Integrated Under One Roof

By maintaining our own induction foundry, casting facility, CNC machine shop, and testing benches on-site, Allied Engineering guarantees absolute control over metallurgy, dimensional accuracy, and timely project deliveries.

Request Factory Visit / Audit
